Description
LEADER® AC MCB LAM7 is used in solar distribution system or home distribution system for protecting overload and short circuit in the systems.It is novel in structure, light in weight, reliable and excellent in performance.It has high breaking capacity and can trip quickly. Its case and body are made of highly fire-retardant and shockproof plastic.This product with long life, is mainly used in AC 50Hz / 60Hz single-pole 240V or two / three / four-pole 415V circuit for overload and short circuit protection. The products following standards GB10963 and IEC60898.
- AC MCB & 1P/2P/3P/4P & 240V-415V & 1-63-125A
- AC MCB Circuit Breakers Designed For PV Solar System
- Has Overload Long Delay Protection, Short Circuit Protection
- Quick Closing And Fast Reading Segmentation & Small Size
- Our Solar Products Have Connected Over 26GW By 2022
- Contact Now, Quote Online & Support The Free Samples
Specification Of AC MCB
| Product NO. | LLA7-PV | Endurance | ≥4000 |
| Number of Poles | 1P,2P,3P,4P | Circumstance Temperature | ‘-5℃~+40℃ |
| Rated Current | 6,10,16,20,25,32,40,50,63,80,100,125(A) | Electrical Life | No less than 6000 operations |
| Breaking Capacity | 6000(A) | Mechanical Life | (o-c) no less than 20000 operations |
| Rated Voltage | 230/415(V) | Protection Level | IP20 |
| Rated Frequency | 50/60Hz | Standard | IEC60898,GB10963 |
Drawing Of AC MCB Types
Characteristic Curve
Please download the datasheet : AC MCB
Production Processes of Cable Connector
First of all,we need to die casting pins.Then,inject plastic into it.Next,use machine to assembly positioning shrapnel.Fourth,auto assembly O-ring and connector.After assembly,it’s the processes of testing.Firstly,test its resistance.Secondly,test its pull. Thirdly,test its water proof.What’s more,test its wet insulation.At last,plastic closures and package.
Standard Package Info:
| Carton Dimension(cm) | Pack list | QTY | Gross weight(kg) |
| 42.5cm × 23.5cm × 35cm | AC MCB | 120pcs | 22.2kg |
Contact us now, Free sample is available
To find out more information about our products and services, send us a message and one of our PV experts will get back to you. We look forward to assisting you.
